The group of barbed wire with unidirectional
twist require take up unit of rotary type and this is placed below the table
of the barbing unit and mounted on the stands on which the Prem barbing unit
stands. The necessary transmission of power off the barbing unit is also
incorporated.
Take-up unit for the reverse twist Prem
barbed wire as also Mono Barbed wire is same and can be supplied either twin
take up or single take up unit. This take up unit is mounted on brackets on the
stand at the front end of the Prem barbed wire unit, the end from which the
finished barbed wire emerged. The necessary power transmission of the barbing unit
is incorporated.
| Group
A Barbed wire with uni-directional twist |
| 1.
.......................Glidden 2 Point |
| 2.
.......................Glidden 4 Point |
| 3.
........................IOWA 2 Point |
| 4.
........................IOWA 4 Point |
| 5.
........................Domingo 2 Point |
| 6.
.........................Domingo 4 Point |
| Group
B Reverse twist Barbed Wire |
| 7.
.........................2 Point |
| 8.
.........................4 Point |
| Group
C single strand Barbed wire |
| 9.
.........................Mono Barbed Wire |
| 10.
.......................Concertin a short barb |
|
|
| Barb
Spacing |
75 mm |
100 mm |
| Group
A |
20 |
25 |
| Reverse
Twist |
20 |
30 |
| Horse
Power Required |
5 H.P. |
5 H.P. |
| Output |
120-240
Barbs/Min |
120-240
Barbs/Min |
| Production
Capacity |
500
-600
Kg |
550
-650
Kg |
NOTE: Design
& Specifications of Machines are Subject to Change without any prior notice.
|
