Overhung Eccentric Slotter

Three slots and one corner cutting is done simultaneously on this machine. The distance between   slotting and corner cutting heads are adjustable with gear and rack mechanism provided with the machine. Two side gauges are provided for  accurate feeding. Minimum distance between two dies is 7"  Corner width is 3.5"
Technical Specification
Size Motor H.P. Max. Slot Depth Wt. App. (MT). Floor Space
65" 2.0 18" 1.8 '7x4'
75" 3.0 18" 2.2 8'x4'
85" 3.0 18" 2.5 9'x4'
95" 5.0 18" 3.0 10'x4'
